MENRED 3.5kW Inverter 5.83kWh Battery All-In-One Home Storage System

Short Description:

This residential ESS is with 3.5kW off-grid single-phase inverter and 5.83kWh battery module.

Our off-grid AIO energy storage system features with integrated AC charger, up to 80A charging current.

Our BMS communicates with inverters via CAN protocol, which increase systems stability and lifetime.


  • Brand: Menred
  • Model: ESS.5835
  • Max. AC Output Power: 3.5 kW
  • Battery Capacity Range: 5.83 kWh
  • Weight (Inverter): 60 KG
  • Dimensions : 498mm x 320mm x 600mm
  • Warranty: 5 Years
  • Product Detail

    Specs

    About Us

    FAQ

    Product Tags

    博优00030001

    博优00030003

    博优00030002

    公司照片合作企业


  • Previous:
  • Next:

  • Inverter
    Rated Power 3500W
    Peak Power 7000W
    AC Input Voltage 230V (170-280V For Personal Computers, 90-280V For Home Appliances)
    AC Output Voltage 230±5%
    Bypass Transfer Time 10ms For Personal Computers, 20ms For Home Appliances
    Wave Form Pure Sine Wave
    Frequency 50Hz/60Hz (Follow Grid)
    Battery
    Battery Type LFP (LiFePO4)
    Battery Cell CATL 3.2V/227Ah / 1P8S
    Nominal Capacity 25.6V/5.83kWh
    Cycle Life >5000 Times @ 0.5C & 25℃
    Solar & AC Charger
    Max. PV Input Power 5000W
    MPPT Input Range 120V~450V
    Max. PV Charge Current 100Amp
    Max. AC Charge Current 80Amp
    Max. Total Charge Current 100Amp
    Dimension (L x W x H) 498mm x 320mm x 600mm
    Net Weight 60KG
    Gross Weight 70KG

    Ningbo Skycorp Solar Co, LTD was established in April 2011 in Ningbo High-Tech District by a team of elites. Skycorp is always committed to become the most influential solar company in the world. Since our establishment, we focus on the research and development of solar hybrid inverter, LFP battery, PV accessories and other solar equipment.

    At Skycorp, with a long-term perspective, we have been laying out the energy storage business in an integrated manner, we always take customers’ demand as our first priority, and also as a guidance for our technological innovation. We strive to provide efficient and reliable solar energy storage systems for global families.

    In the field of solar energy storage system, Skycorp has been serving continuously for many years in Europe and Asia, Africa and South America. From R&D to production, from “Made-In-China” to “Create-In-China”, Skycorp has become a leading supplier in the field of mini energy storage system.

    Frequently Asked Questions from our customers:

    1. Do you offer samples for testing purposes?
    Yes, we do offer sample machines for testing. Please specify your requirements when contacting our agents.

    2. What certificate do you have for inverters?
    CEI 0-21, VDE 4105-AR-N, VDE 0126-1-1, EN 50438, G99, G100, AS4777.2, NRS 097, EN 50549, C10/C11, UNE, UTE, NCRfG/PTiREE

    3. Do you support OEM?
    Yes, we do support OEM, however, there’s a requirement on quantities of your order.

    4. What kind of shipment do you offer?
    We offer land, sea, and air freight upon your request. Fees vary.

    5. How long does it take to receive the goods I ordered?
    For samples, the fastest you can receive them is within one week.
    For bulk orders, dates may vary depending on quantity.
